One Solution for all type of CT PT Testing
Compact and portable lightweight instrument for field testing
The ct pt analyzer simply tested your CT’s & Pt’s. This kit will check each and every parameter of CT’s & Pt’s. The ct pt testing equipment can find you Volt -ampere characteristic curve, Turns Ratio Measurement, Primary current Injecting Set, Calculate inflection point value automatically, Draw out 5 % and 10% error curve automatically, Polarity judgement, Ratio Error Measurement, Phase angle difference measurement, AC voltage withstand Test, Secondary Load Testing, Secondary Winding Test.
Call Us +91 727-835-4202
Latest
Related Products
Have a Full Control
Light Weight to Carry Easily
The CT PT Testing Equipment by the top ct pt testing equipment manufacturers in India will offer you lightweight attributes that will ease up its operation. You can take it with you in the fieldwork and simply use it in the substation. The device has weight as low as 22kg and can save the 3000 sets of test data without worrying about the failure of the apparatus. Just use the ct pt testing equipment suppliers in India to test the ct pt frequently.
View More
MODELS Of CT PT TESTING EQUIPMENT
- Available in filter cartridge models.
- Available in Capacity Up-to 600 LPH.
- Major pipe connections are made of wire braided hoses.
- Ball valves with SS balls and Teflon seating.
- Rugged construction, resulting in long years of service.
- Centralised control panel (Fuse less panel using MCCBs, MCBs).
- Imported filter cartridges.
- Powder coated outer panels and internal parts spray painted with PU Paint.
- Temperature gauge, vacuum gauge, compound gauge, Safety relief valves.
- Mounting options like mobile (with Jeep Wheel), semi-mobile (with castor wheel) and skid.
- Improves dielectric strength of the Transformer oil from 25 KV to 65 KV & above In 3 to 4 Passes.
| Parameters | Unit | Value |
| Flow Rate | L/H | 600 |
| Inlet Pump | L/M | 20 |
| Outlet Pump | L/M | 20 |
| Heating Power | KW | 9 |
| Vacuum Pump | L/M | 200 |
| Inlet/Outlet | mm | Φ12 |
| Magnetic Strainer | Micron | 50 |
| Secondary Filter | Micron | 2 No.10µ 2 No. 1µ |
| Operation Temperature | ℃ | 40 ~ 70 (65°C is best) |
| Power Supply | – | 390-450 VAC, 3 Phase, 50 Hz |
| Ambient Temperature | ℃ | -25 ～ 55 |
| Weight | KG | 350 |
| Inlet/Outlet Hose Pipe | Meter | 10 Meter Each. |
| Parameter | Used Oil | After Treatment |
| Moisture(Water Content) | ≥20 ppm | ≤ 5-10 PPM |
| Gas Content | 10% | ≤0.1% (Vol) |
| Particle size (Filtration Level) | 50-100 micron | ≤ 1 micron |
| Breakdown Voltage(Dielectric) | 25 kV | ≥ 65KV |
When this machine start working and vacuum degree is upto the set value, the used oil will be sucked into the primary filter & secondary filter under the pressure difference, the primary filter & secondary filter will remove the big size impurities/ particles, then the oil which just contains the tiny particles is heated by the heaters. Then the heated oil enter into the vacuum separator, through the function of vacuum pressure and degassing system, the moisture content in the oil, which is vapoured & separated from the oil quickly, is either discharged under the process of the vacuum system or refrigerated to liquid water into water receiver, meanwhile de- gasification work is completed. The last procedure is that the fine filter removes the tiny impurities completely. Finally, clean oil goes out through the oil outlet.
