4500 LPH Capacity Hydraulic Oil Filtration Equipment for Maximum Filtration
Maximum Filtration Capacity
The product is top class and can give you filtration of up to 4500 LPH capacity. Therefore, you can put in the maximum oil and free the maximum pollutants from the machine that has pollutants in oil. Being a manufacturer, we know that companies that make diverse oil based machines require cleaning of the nonessential elements that are present in the oil for the further function of the machine. With hydraulic oil filtration equipment suppliers products, you can remove the oil impurities in Hydraulic Oil.
Download Catalogue
View More
PRODUCT GALLERY
SS Ball Valves Enabled Device for Full Control of Material
We made hydraulic oil filtration equipment with the SS ball valves that will have a control system for the entering and exit of the liquid. You have full control over the machine, as you can only release the worthless liquids at your convenience. We equip these ball valves with Teflon coatings to ensure no single drop of liquid leaks without your permission. Thus, this hydraulic oil filtration manufacturers product is doing wonders for many industries and helping them ease up the cleaning process of their hydraulic oils.
| Description | Unit | HOFM 500 | HOFM 2000 | HOFM 4500 |
| Flow Rate | L/H | 500 | 2000 | 4500 |
| Inlet Size | Inch | 1/2 | 1 | 1.5 |
| Outlet Size | Inch | 1/2 | 3/4 | 1.5 |
| Inlet Pump | L/H | 1200 | 2400 | 4800 |
| Outlet Pump | L/H | 1200 | 2400 | 4800 |
| Inlet Motor | HP | 1 | 1.5 | 3 |
| Outlet Motor | HP | 1 | 2 | 5 |
| Heater | KW | 6 | 24 | 54 |
| Degassing Stage | – | Single | Single | Single |
| Vacuum Pumping System | LPM | 200 | 500 | 1000 |
| Vacuum Degree | Torr | 5 | 5 | 5 |
| Working Pressure | Barr | 5 | 5 | 5 |
| NAS Value | – | 6 | 6 | 6 |
| Water Content | PPM | 10 | 10 | 10 |
| Particle Size | µm | 2 | 2 | 2 |
| Temperature Range | ºC | 60 | 60 | 60 |
| Machine Type | Movable | Skid Mounted | Skid Mounted | Skid Mounted |
- Continuous Filtration.
- System can achieve NAS 6 from NAS 9.
- Based on filter cartridge and vacuum dehydration
- Available in Different flow capacities like 500 -4500 LPH.
- Hydraulic Oil Cleaning Machines is portable oil cleaning and filtration system.
- The filtration system is capable of removing the solid contamination as well as moisture.
- Coal & metal mines.
- Pulp & paper plant.
- Steel & rolling mills.
- Cement mills & RMCs.
- Automobile manufacturing.
- Pressing, stamping, forging & foundry.
- Non-ferrous mineral plants – A1/Zn/Pb etc.
- Power plants – Coal, Gas, Hydro, Nuclear, Wind, Bio-mass.
- Hydraulic oil Contamination causes aging/degradation of fluids and hydraulic systems failure for numerous reasons.
- Contamination decreases the ability of valves to control flow and pressure, thus wasting horsepower and generating
excess heat.
